Chamsys MagicQ Rack

The ChamSys MagicQ Rack delivers full MagicQ console functionality in a compact 19" 1U rack-mountable form factor, purpose-built for permanent installations and architectural lighting control. Running the same robust MagicQ operating system found in ChamSys consoles, this versatile unit supports up to 24 universes of DMX output (expandable to 48) and offers powerful integration tools such as OSC, UDP, MIDI, and scheduled events.

MagicQ Rack is ideal for venues, theatres, houses of worship, and themed environments needing a professional-grade control system that doesn’t rely on a traditional console interface. It features ten programmable buttons for activating Playbacks and Executes and integrates easily with ChamSys 10Scene wall plates via its four 10Scene ports—allowing control from up to 40 external wall stations.

Equipped with RDM-enabled DMX outputs, built-in Wi-Fi for programming or remote focus, and external HDMI display support, this system is streamlined for performance and configurability.

Key Features:

• 24 Universes Standard, expandable to 48 via license upgrade

• Two 5-pin RDM-enabled DMX Outputs for direct fixture control

• Ten Playback/Execute Buttons for local scene recall

• Four 10Scene Ports for up to 40 wall plates

• Built-in Wi-Fi for MagicQ Remote App and configuration

• 1x HDMI Output for external monitor support

• OSC, MIDI, UDP & Timecode Support

• Runs MagicQ Stadium Software — including MagicVis, MagicHD, and full FX engine

• TrueCon Power Input, low power consumption (60W max)

• Compact 1U rackmount form with included ears

• (1) Wi-Fi Antenna

• (2) Rack Ears

• (4) 10Scene Connectors

• (1) Neutrik powerCON TRUE1 Power Cable

• Dimensions (Console): 403 x 195 x 45 mm

• Weight (Console): 3.1 kg

• Universes (Standard/Max): 24 / 48

• DMX Ports: 2 x 5-pin XLR

• USB Ports: 2

• Network Ports: 1

• Audio I/O: Yes

• MIDI I/O: Yes

• External Monitor Support: HDMI (1920x1080)

• Max Cues / Stacks / Groups: 5000 / 2000 / 5000

• Fixture Library: Over 48,000 profiles
